Name: Original Factory Cell Load 30 Ton Keli Load Cell Sensors Jembatan Timbang Grains HM9B for Weighbridge Timbangan
Brand: Changzhou Skyerscale Co.,Limited
SKU: HM9B
Price: 117.00 USD
Availability: InStock

Original Factory Cell Load 30 Ton Keli Load Cell Sensors Jembatan Timbang Grains HM9B for Weighbridge Timbangan

10pcs

MOQ

Negoziabile

prezzo

Caratteristiche Galleria Descrizione di prodotto Richieda una citazione

Caratteristiche

Specificazioni

Materiale: Acciaio in lega

Teoria: Sensore di resistenza

Produzione: Sensore analogo

Utilizzo: Sensore di pressione

nome: cella a carico di bassa forza

Carico nominale: 30T

Informazioni di base

Luogo di origine: Cina

Marca: ZEMIC

Certificazione: OIML

Numero di modello: HM9B

Termini di pagamento e spedizione

Imballaggi particolari: Cartoni e pallet

Tempi di consegna: 5-15 giorni

Capacità di alimentazione: 1000pcs/m

Galleria

Original Factory Cell Load 30 Ton Keli Load Cell Sensors Jembatan Timbang Grains HM9B for Weighbridge Timbangan

Descrizione di prodotto

Original Factory Cell Load 30 Ton Keli Load Cell Sensors Jembatan Timbang Grains HM9B for Weighbridge Timbangan

Specifications:

Capacity	t	10/20/25/30/40SE/40/50
Accuracy		C1	C2	C3	A5M	B10M
Approvals				OIML R60 C3
Maximum number of verification intervals	n max	1000	2000	3000	5000	10000
Minimum load cell verification interval	v min	Emax/3000	Emax/5000	Emax/7500	Emax /15000	Emax /10000
Combined error	(%FS)	≤±0.050	≤±0.030	≤±0.020	≤±0.026	≤±0.050
Creep	(%FS/30min)	≤±0.038	≤±0.024	≤±0.016	≤±0.017	≤±0.040
Temperature effect on sensitivity	%FS/10℃)	≤±0.028	≤±0.017	≤±0.011	≤±0.013	≤±0.040
Temperature effect on zero	(%FS/10℃)	≤±0.047	≤±0.023	≤±0.015	≤±0.014	≤±0.020
Output sensitivity	mv/v)	2.0±0.002	2.3±0.002	2.4±0.002	1.9±0.002	1.8±0.002
Input resistance	(Ω)	700 ±7			775 ±5	750 ±7
Output resistance	(Ω)	700 ±7
Insulation resistance	(MΩ)	≥ 5000(50VDC)
Zero balance	(%FS)	1.5
Temperature, compensated	(℃)	-10~+40
Temperature,allowed	(℃)	-35~+65
Excitation, Recommended	(V)	5~12(DC)
Excitation,Max	(V)	18(DC)
Safe overload	(%FS)	150
Ultimate overload	(%FS)	300

Outline Dimension mm(inch):

Original Factory Cell Load 30 Ton Keli Load Cell Sensors Jembatan Timbang Grains HM9B for Weighbridge Timbangan 0

Capacity:10t to 50t.
High accuracy.
Alloy steel construction.
Easy installation, reliable performance.

Description:

1. HM9B load cell are available in the capacities 10t to 50t.
2. Alloy steel construction, nickel plated , hermetically welded,oil-proof,waterproof and anti-corrosive gas and medium making ,it suitable for all kinds of environments.
3. Dual shear beam, Suitable for electronic truck scales,railway scales and other electronic weighing devices.
4.It is safety and anti-explosion product that can be used in atrocious weather and hazardous areas.

Original Factory Cell Load 30 Ton Keli Load Cell Sensors Jembatan Timbang Grains HM9B for Weighbridge Timbangan 1

Original Factory Cell Load 30 Ton Keli Load Cell Sensors Jembatan Timbang Grains HM9B for Weighbridge Timbangan 2

Applications:

It is used in truck scale/weighbridge

Competitive Advantage:

OEM is available
24 hours online service
Inquiry will be replied in 2 hours
One year warranty
1% free spare part
Free parts for any breakdown with convincing evidence
